Fully Automatic High-Precision Cross-Cutting Machine
Green Ohm Machinery is a professional manufacturer and supplier of slitting and cutting machines. Our Fully Automatic High-Precision Cross-Cutting Machine , was our pioneering development. We adhere to the philosophy of "Quality First" and warmly welcome overseas customers to visit our factory.
Product Applications
Green Ohm Machinery specializes in packaging equipment, including cross-cutting and slitting machines. With a professional engineering team and advanced processing, we develop innovative solutions for global markets. Our products are exported to America, Europe, and Asia, enjoying wide popularity and high user satisfaction.
The Fully Automatic High-Precision Cross-Cutting Machine is suitable for all kinds of office paper, high-gloss paper, paper and plastic composite packaging material such as roll cutting.
Key Features
Advanced PLC Touch Screen Control
Equipped with a PLC touch screen and servo motor for precise, constant-length cutting.
Pneumatic & Photoelectric Transmission Control
Combines pneumatic operation with photoelectric sensors to manage the transmission system, offering easy operation, high precision, stable performance, and low noise.
Automatic Functions for Efficiency
Includes frequency converter timing, automatic counting, and magnetic powder tension control.
Machine automatically stops in case of errors or material shortage.
Vertical cutting is supported, and a blower removes waste material for a cleaner workflow.
Flexible Roll Loading Options
Compatible with 1-roll, 2-roll, or 4-roll loading systems, providing versatility for various production needs.
Technical Parameter
|
Model |
A1100-4R |
A1400-4R |
|
Max cuttig width |
1100mm |
1400mm |
|
Max diameter of material |
Φ1400mm |
Φ1400mm |
|
Vertical Min width of slitting |
50mm |
50mm |
|
Cutting length |
200-150mm |
200-1500mm |
|
Cutting speed |
10-150times/min |
10-150times/min |
|
Material thickness |
30-500g |
30-500g |
|
Cutting precision |
±0.2mm |
±0.2mm |
|
Total power |
16kw |
18kw |
|
Weight |
8000kg |
10000kg |
|
Overall dimension (L*W*H) |
19000X2200X2200mm |
19000X2500X2200mm |
